How to Host a React and Node.js App using Caddy and Docker

Overview – Caddy, Docker, React, Node.js

In this blog post, I’m going to share how, you can setup a reverse proxy to host a React and Node.js app from a single server – all while having automatic SSL. Here are the technologies used:

Docker
Caddy
A React front-end
A Node.js back-end

Hosting?

You’ve built your React front-end and a Node.js back-end. It all works beautifully using Vite‘s local hosting options. You’d now like embark on hosting this publicly and ensure you have SSL certificates – which are automatically renewed.
This means, you’d need to solve for a few aspects:

Hosting the front-end application
Hosting the back-end server
Ensuring the above have SSL certs

Cloud hosting solutions are ubiquitous these days – DigitalOcean’s AppPlatform, Netlify, Vercel, etc. These are convenient and provide a relatively quick way to host your services, however, there is an alternative – hosting these yourself on a virtual private server (VPS).
The self-hosting route takes a bit more effort and your application may not easily scale, but for the project I had in mind, these weren’t a big enough blocker. Hence, if I opted for the latter option.

Self-hosting

Solving the reverse proxy problem

Why do I need a reverse proxy?

A reverse proxy is the system/tool that can redirect all requests that are made to a single public IP address to specific applications internally.
For example:
Your VPS has a public IP of 172.14.1.129. When you setup a DNS record to point to that public IP, all traffic will be routed there. There’s no distinguishing between the front-end and back-end at this point. Herein lies the value of a reverse proxy. We can setup the following DNS records:

Front-end (React): myapp.com -> 172.14.1.129
Back-end (Node.js): api.myapp.com -> 172.14.1.129

Then, the reverse proxy will do the following:

Front-end (React): myapp.com -> 172.14.1.129 -> Reverse Proxy -> Redirect to internal React app IP address
Back-end (Node.js): api.myapp.com -> 172.14.1.129 -> Reverse Proxy -> Redirect to internal Node.js app IP address

Choosing your reverse proxy tool

In a previous blog post, I used a tool called Traefik and it worked well for what I needed at the time.
Instead of using Traefik again, I stumbled upon Caddy. I was intrigued by the minimal configuration required so decided to give it a try.

Using Caddy

To use Caddy, you will need the following:

A Caddyfile where you define how you’d like your reverse proxy to function
Additional config within your docker-compose.yml file

The project directory is as follows:

root
- client/
  - Dockerfile
- Dockerfile (for server – Nodejs) – thinking about this more, I should have created a separate directory to house all Nodejs/server code
- Caddyfile
- docker-compose.yml

Here’s an example of the Caddyfile I used:
Caddyfile:

// Back-end API (Node.js)
api.example.com {
  reverse_proxy server:5000 { // server - referes to the docker service name
    header_down Strict-Transport-Security "max-age=31536000"
  }
}

// Front-end app (React)
example.com {
  root * /srv
  try_files {path} /index.html
  file_server
}

This docker-compose.yml file that has the following services:

server – the Node.js server
client – the React front-end
caddy – Caddy used for reverse proxy

version: "3.7"
services:
  client:
    container_name: client
    build:
      context: ./client
      dockerfile: Dockerfile
    networks:
      - network
    volumes:
      - app-dist:/app/client/dist # Mount the app-dist volume to the dist directory

  server:
    container_name: server
    build:
      context: .
      dockerfile: Dockerfile
    ports:
      - "5000:5000"
    restart: always
    environment:
      "NODE_ENV": "production"
    networks:
      - network
    # Run the caddy server
  caddy:
    image: caddy/caddy:2.7.5-alpine
    container_name: caddy-service
    restart: unless-stopped
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./Caddyfile:/etc/caddy/Caddyfile
      - app-dist:/srv  # Mount the app-dist volume to the Caddy service
      - caddy_data:/data
      - caddy_config:/config
    networks:
      - network
    depends_on:
      - server
      - client

volumes:
  app-dist:
  caddy_data:
  caddy_config:


networks:
  network:
    driver: bridge

Here is the Dockerfile used for the client (React) front-end:

# Use an official Node.js image as the base image
FROM node:20 as builder
# Set the working directory
WORKDIR /app/client
# Copy package.json and package-lock.json to the working directory
COPY package*.json ./
# Install dependencies
RUN npm install
# Copy the entire client directory to the working directory
COPY . ./
# Build the production version of the React app
RUN npm run build
# This is important as it's referenced in the docker-file
VOLUME /app/client/dist

All that’s left for you to do is run docker-compose up -d and if all goes well, you’ll have both your React and Node.js app with automatic SSL certificates hosted on a single VPS.

Troubleshooting Caddy

Caddy SSL not working?

Did you delete `caddy_data`?

caddy_data contains your SSL certificates, to avoid rate limits from Lets Encrypt, avoid deleting this volume frequently

Reverse proxy isn’t working?

Check which port your service is running on

Make sure you’re using the docker internal service IP (e.g. for my server I’m using port 5000) in your Caddyfile

Ensure you’re using the service name

Make sure you’re referring to the docker service name in your Caddyfile. Notice I’m using server:5000

Conclusion

Using Caddy as a reverse proxy for a React and Node.js app, all hosted on a single server took minimal effort and it works! The automatic SSL that Caddy provides is invaluable for anyone self-hosting secure apps.
